Filmetrics® F10-AR
The F10-AR is designed for simple, affordable measurement of ophthalmic anti-reflection coatings and hardcoat thickness measurements.Filmetrics F10-AR coating measurement instrument contains several proprietary advances that allow line operators to make conclusive readings of anti-reflection coatings in seconds, and with only minutes of training. Hardcoat thickness, even in the presence of AR layers, can be measured with our optional UPG-F10-AR-HC software upgrade. Minimum, maximum, and average reflectance can be go/no-go tested over any number of user-defined wavelength ranges. A special algorithm allows for the correction of localized reflectance distortions caused by hardcoat layers. Our proprietary AutoBaseline feature results in vastly increased baseline intervals and provides better accuracy than other fiber-probe-based reflectance measurement systems.Our exclusive probe design also rejects 98% of backside reflections on substrates 1.5mm thick, and rejects even more on thicker lenses, removing the need for backside preparation.
