LT-AFM/MFM 低温显微镜

LT-AFM/MFM | Low Temperature Microscope

The LT-AFM/MFM is an alignment-free Atomic Force Microscopy system equipped with a Fibre Interferometer operating at 1310 nm, 15 fm/√Hz noise level with an operation range of 20mK-300K, and up to 16T magnetic field.

LT-AFM/MFM | Low Temperature Microscope

Cryogen Free MFM/AFM

Rigid AFM design
Magnetic Force Microscope
Atomic Force Microscope
Scanning Hall probe Microscope
EFM,PFM,SSRM,STM,etc.

Cryogen Free Cryostat

Vibration free design
100% dry system
Closed – Cycle
温度范围 1.5K – 400K
Up to 20 Tesla
Low operating costs

Sample Approach:Stick-slip type;10mm Z,Q3mmXY range with 50-800nm
Fine Sample Positioning:Capacitive encoder with 2um resolution
Sample Size:15x15x5mm maximum
Sample Holder:5 pins connections for experiments:One bias voltage,4 spares
Temperature Range:1K-300K(Limited by the system)
Magnetic Field:up to 20T
Compability:PPMS@.PPMS⑧Evercool can also be compatible with switched offcompressor during experiments.Dilution Refrigerators and He3systems.Can be customized to fit in to other mK systems or cryostatif free space permits.
兼容性：兼容 PPMS®；PPMS® Evercool 实验时可兼容关闭压缩机；兼容稀释制冷机和 He3 系统；空间允许时可定制适配其他 mK 系统或低温恒温器
