USB Fiber Interferometer

Complete Fiber Interometer System for Atomic Force Microscopes.Modulation frequency & Amplitude are controlled from software for noise reduction

System Specification



Laser



  • Wavelength : 1310 nm

  • Noise Level : ~10fm/√Hz, @ 2mW typical

  • Optical Out Power : 20µW - 2mW adjustable in 100 steps or 2µW - 200µW , adjustable in 100 steps or 200nW - 20µW , adjustable in 100 steps



RF Modulation



  • Modulation frequency & Amplitude are controlled from software for noise reduction



Photodiode Module



  • Signal & Reference lnGaAs Photodiodes

  • Photodiode Gain Control : x 1, x2, x4, x8

  • Off-Set DAC Resolution : 16Bit

  • Spare DAC Range : 10 V



Power Requirements



  • 240/220/110/100 VAC selactable, 50/60 Hz 100 VA



Physical Dimensions



  • ~250x 350 x 100 mm



PC Connection



  • USB 2.0 High Speed, 480 Mbps



Environment



  • Maximum operating temperature of 30°C maximum 30% relative humidity
